LED All-in-One Machine A1

Transform your visual presentations with our cutting-edge LED All-in-One Machine A1. Designed for seamless integration and effortless setup, this sleek unit combines all essential components into one powerful device. Experience breathtaking 4K resolution and HDR support, delivering vibrant, crystal-clear images that captivate your audience. Perfect for professional environments, our LED All-in-One Machine A1 enhances your visual impact and elevates your brand’s sophistication and elegance. Make a lasting impression with technology that combines high performance with stunning design.

  • Android OS, equipped with high-performance chips, Cortex A73*2+A53*2. MaliG51 *4 image processor, HD input resolution up to 3840*2160@60 Hz.
  • Standard 4G/32G running storage, fast response, smooth running and stable operation.
  • The machine is made of die-cast aluminum to ensure the flatness of physical splicing; the segmented aluminum rear cover and frame are designed with a thin machine and ultra-narrow frame, and the whole
    is simple.
  • It uses convenient wall hanging and movable hanging with adjustable bracket height, easy installation, and full front maintenance.
  • The user can start the machine with one key without debugging and training.
  • It supports multi-device access and flexible collocation to realize various local and remote voice and video conference scenarios for users.



Model available: A1-108, A1-135, A1-162

Categories: ,

  • Display Size: 108-inch
  • Dot Spacing: 1.25 mm
  • Visible Area: 3.24m²
  • Overall Dimensions (WxH): 2412 x 1418.1mm
  • Screen Resolution (WxH): 1920 x 1080
  • Pixel Density: 640.000 dot/m²
  • Box Flatness: ≤ 0.15 mm
  • Maintenance Method: Full front maintenance
  • IP Protection Level: IP50
  • Encapsulated Type: SMD1010
  • Single-point Luma Correction: Support
  • Single-point Color Correction: Support
  • Brightness of White Balance: 400 cd/m² (adjustable)
  • Refresh Rate: 3840 Hz
  • OS: Standard Android 8.0
  • Sound Brand: Yamaha

Download

  • Display Size: 135-inch
  • Dot Spacing: 1.5625 mm
  • Visible Area: 5.06m²
  • Overall Dimensions (WxH): 3012 x 1755.5 mm
  • Screen Resolution (WxH): 1920 x 1080
  • Pixel Density: 409.802 dot/m²
  • Box Flatness: ≤ 0.15 mm
  • Maintenance Method: Full front maintenance
  • IP Protection Level: IP50
  • Encapsulated Type: SMD1010/SMD1212
  • Single-point Luma Correction: Support
  • Single-point Color Correction: Support
  • Brightness of White Balance: 400 cd/m² (adjustable)
  • Refresh Rate: 3840 Hz
  • OS: Standard Android 8.0
  • Sound Brand: Yamaha

  • Display Size: 162-inch
  • Dot Spacing: 1.875 mm
  • Visible Area: 7.29m²
  • Overall Dimensions (WxH): 3612 x 2093 mm
  • Screen Resolution (WxH): 1920 x 1080
  • Pixel Density: 284.444 dot/m²
  • Box Flatness: ≤ 0.15 mm
  • Maintenance Method: Full front maintenance
  • IP Protection Level: IP50
  • Encapsulated Type: SMD1515
  • Single-point Luma Correction: Support
  • Single-point Color Correction: Support
  • Brightness of White Balance: 400 cd/m² (adjustable)
  • Refresh Rate: 3840 Hz
  • OS: Standard Android 8.0
  • Sound Brand: Yamaha
